HMC8415 数据手册-pdf中文资料-产品介绍及应用电路

HMC8415产品信息：

概览

优势和特点
产品详情

优势和特点

High output power: 46 dBm typical at P(IN) = 23 dBm
High small signal gain: 32.5 dB typical
High power gain: 23 dB typical at P(IN) = 23 dBm
Frequency range: 9 GHz to 10.5 GHz

High power added efficiency: 40% typical at P(IN) = 23 dBm
Supply voltage: V(DDxA)/V(DDxB) = 28 V at 1000 mA
6 mm × 6 mm, 40-lead LFSCP

产品详情

The HMC8415LP6GE is a gallium nitride (GaN), power amplifier, delivering 40 W (46 dBm) with more than 37.5% power added efficiency (PAE) across a bandwidth of 9 GHz to 10.5 GHz.

The HMC8415LP6GE is ideal for pulsed applications, such as wireless weather, marine, and military radar applications.

Applications

Weather radars
Marine radars
Military radars
